Manufacturer: PIX-LINK
Code: LV-AC12
In stock: 0 |
• Extends 2.4 and 5 GHz WiFi signals from existing WiFi routers for better range.
• Dual band WiFi up to 1200Mbps.
• MU-MIMO for simultaneously streaming to multiple devices.
• FastLane technology improves performance using both WiFi bands.
• Convenient wall plug design for easy, discreet placement.
• Works with any WiFi router.
HARDWARE FEATURES
Plug Type UK
Standards IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Interface 1 * 10/100Mbps LAN Port
1 * 10/100Mbps LAN/WAN Port
Button WPS Button, Reset Button
Antenna 2 * external
Dimensions ( W x D x H ) 88 x78.0 x 40.5mm
WIRELESS FEATURES
Frequency 2.4GHz & 5GHz(11ac)
Signal Rate 5GHz:Up to 867Mbps
2.4GHz:Up to 300Mpbs
Reception Sensitivity 5GHz:
11a 6Mbps:-93dBm@10% PER
11a 54Mbps: -76dBm@10% PER
11ac HT20 mcs8: -69dBm@10% PER
11ac HT40 mcs9: -64dBm@10% PER
11ac HT80 mcs9: -61dBm@10% PER
2.4GHz
11g 54M: -78dBm@10% PER
11n HT20 mcs7: -75dBm@10% PER
11n HT40 mcs7: -73dBm@10% PER
Transmit Power <20dBm(2.4GHz)
<18dBm(5GHz)
Wireless Modes Repeater/AP/Router
Wireless Security 64/128/152-bit WEP
WPA-PSK / WPA2-PSK
OTHERS
Package Contents 1xWireless-AC Repeater/AP/Router
1xRJ-45 Ethernet Cable
1xQuick Installation Guide
Environment Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
