Manufacturer: EDUP
Code: EP-AC1601
In stock: 0 |
Features:
1.Support USB3.0
2.Support 20MHz/40MHz/80MHz frequency
3.5G compatible with IEEE 802.11ac and IEEE 802.11a standard
4.2.4G compatible with IEEE 802.11n, IEEE 802.11g, IEEE 802.11g standard
5.Detect the network and change transmit speed automatically
6.Support WPA/WPA2/WPA-WPA2/802.1x and 64/128 bit WEP encryption
7.Support WPS 2.0
8.Internal Omni-directional Antenna
9.Support 2.4G and 5G dual band
10.Support Wi-Fi Direct
11.Support Multiple BSSID
12.Support QoS-WMM, WMM-PS
13.Support WPS: PIN, PBC
14.Support Infrastructure mode, Ad-Hoc mode and Soft AP three modes
15.Support Cisco CCX
16.Low consumption management
17.Supported Window 2000/XP/Vista/Win7/Win8/Win8.1/Win10; Mac OS10.9~10.11; Linux v3.0.0.1
Specification:
Wireless Standards IEEE 802.11n
IEEE 802.11g
IEEE 802.11b
IEEE 802.11ac
IEEE 802.11a
Transmit Speed 802.11b: 1/2/5.5/11Mbps
802.11g: 6/9/12/18/24/36/48/54Mbps
802.11n: up to 300Mbps
802.11n: up to 867Mbps
Frequency Range 2.412~2.4835 GHz
5.180~5.320GHz
5.500~5.700GHz
5.745~5.825GHz
Work Channel 1 ~ 14 (2.4G)
36 ~ 165 (5G)
Chipset MTK7612
Work Power 18dBm (Typical)
Sensitivity 11n: -68dBm@130M; -68dBm@108M
11g: -69dBm@54M
11b: -85dBm@11M
11ac: -59dBm@867M
Wireless Security WPA/WPA2/WPA-WPA2/802.1x
64/128 bit WEP
WPS (PIN, PBC)
Support Operation System Window 2000/XP/Vista/Win7/Win8/Win8.1/Win10; Mac OS10.9~10.11; Linux v3.0.0.1
Host Interface USB 3.0
LED(BLUE) Link/Act
Antenna Type Internal Omni-directional Antenna
Size(cm) 9.1×3×1.2
Environment Operating Temperature: 0℃~45℃
Storage Temperature: -20℃~75℃
Operating Humidity: 10% ~ 90% RH (Non Condensing)
Storage Humidity: 5% ~ 95% RH (Non Condensing)
