WIRELESS USB ADAPTER WITH 6DBI ANTENNA

At 5 times faster than traditional Wireless-G (802.11b) networks, Wireless-N networks allow for high speed data transfers, online gaming, and lightning fast downloads. The Wireless-N USB 2.0 Adapter gives you access to all the high-speed features of Wireless-N networks on older and newer computers. Its simple and easy setup means you’ll be surfing the internet, downloading movies, and e-mail in no time.

MIMO technology improves data throughput and range over existing 802.11b/g productsAdd high-speed Wireless-N (draft 802.11n) Internet access to any USB enabled computerDownload music & movies, surf the internet and e-mail up to 5 times faster than previous generation wireless networks (Wireless 802.11g)Offers greater coverage than Wireless-G networks for internet access throughout your home or officeWorks with older Wireless-G and Wireless-B networksWi-Fi Protected Setup (WPS) simplifies setup and operationOperating distance of up to 300 feet indoor, and up to 900 feet in open spaceData transfer rate of up to 150Mbps (downlink) and 150Mbps (uplink)Supports USB 2.0 interface, backward compatible to USB 1.1 and 1.2Enhanced WEP and WPA wireless security for protected Internet access64-bit / 128-bit WEP (Wired Equivalent Privacy), TKIP, AES 2.400GHz ISMFrequency Band Modulation Method: QPSK / BPSK / 16-QAM / 64-QAMSupports Ad Hoc and Infrastructure modesSupports IEEE 802.11e standard

Specification:

Wireless Standards          IEEE 802.11n (draft)
                                     IEEE 802.11g

                                     IEEE 802.11b

Host Interface            High speed USB2.0/1.1 interface
Data Rate     802.11n: up to 150Mbps (downlink) and 150Mbps (uplink)
                   802.11g: 54 / 48 / 36 / 24 / 18/ 12 / 9 / 6 Mbps auto fallback

                   802.11b: 11 / 5.5 / 2 / 1 Mbps auto fallback

Frequency Band     2.4GHz ISM (Industrial Scientific Medical) Band
Chipset                  MTK7601
External antenna    6dBi
RF Frequency        2412 ~ 2462 MHz (North America)
                            2412 ~ 2472 MHz (Europe)

                            2412 ~ 2484 MHz (Japan)

Radio Channel       1 ~ 14 channels (Universal Domain Selection)
Range Coverage    Up to 3 times farther range than 802.11g
Antenna type        Integrated Antenna
Roaming               Full mobility and seamless roaming from cell to cell
RF Output Power   13 ~17 dBm (Typical)
Modulation           11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
                           11g: BPSK, QPSK, 16QAM, 64QAM, OFDM

                           11b: DQPSK, DBPSK, DSSS, CCK

Data Security        64/128-bit WEP Encryption
                           WPA, WPA-PSK, WPA2, WPA2-PSK. TKIP/AES

Network               Auto-switch to use 802.11n or 802.11g or 802.11b mode
                           Supports Ad-Hoc, Infrastructure WLAN network

                           Wireless roaming

                           Data rate auto fall-back under noisy environment or         longer range distance

                           Site Survey with Profile function

Configuration & Management    Plug-and-Play setup and installation
                                             Management Utility supports 2000 / XP/ Vista

Media Access Control          CSMA/CA with ACK
Operating System               WinXP，WinVista，Win7，Win8，Win8.1，Win10；Linux v3.0.0.4
Environment                      Operating Temperature: 0oC to 40oC
                                        Storage Temperature: -20oC to 75oC

                                        Operating Humidity: 10% ~ 90% (Non Condensing)

                                         Storage Humidity: 5% ~ 95% (Non Condensing)

Compliant                   FCC (USA)
                                 CE Mark (Europe)

                                 RoHS Compliant

                                 Wi-Fi Compliant
