Manufacturer: Huawei
Code: WS5280
| In stock: 0 |
| Technical specifications | Language English |
| Antenna | |
| Antenna type | Internal |
| Design | |
| Product colour | White |
| Product type | Tabletop router |
| Ethernet LAN features | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN | Y |
| Management features | |
| WPS push button | Y |
| Reset button | Y |
| Mobile networking | |
| 4G | N |
| 3G | N |
| Networking | |
| VPN Passthrough | Y |
| Guest access | Y |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
| Operational conditions | |
| Storage relative humidity (H-H) | 5 - 95 % |
| Operating relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Packaging content | |
| Quick start guide | Y |
| Cables included | AC,LAN (RJ-45) |
| Performance | |
| Plug and Play | Y |
| Chipset | RTL8197FS (2x2 Wi-Fi 2.4GHz), RTL8812BR (2x2 Wi-Fi 5GHz 11ac), Hi5630, Hi1151 |
| Memory card slot(s) | N |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 3 |
| USB port | N |
| Power | |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 24 W |
| Power source type | AC |
| Protocols | |
| DHCP client | Y |
| Security | |
| MAC address filtering | Y |
| Security algorithms | AES,TKIP,WPA-PSK,WPA2-PSK |
| WAN connection | |
| WAN connection type | RJ-45 |
| 3G/4G USB modem compatibility | N |
| SIM card slot | N |
| Ethernet WAN | Y |
| Weight & dimensions | |
| Weight | 495 g |
| Height | 183.5 mm |
| Depth | 75 mm |
| Width | 112 mm |
| Wireless LAN features | |
| WLAN data transfer rate (second band) | 867 Mbit/s |
| WLAN data transfer rate (first band) | 300 Mbit/s |
| Wi-Fi standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
| WLAN data transfer rate (max) | 1167 Mbit/s |
| Top Wi-Fi standard | IEEE 802.11ac |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
