Manufacturer: EDUP
Code: EP-AC1669
In stock: 0 |
Features
Support USB2.0
Support 20MHz/40MHz/80MHz frequency
5G compatible with IEEE 802.11ac and IEEE 802.11a standard
2.4G compatible with IEEE 802.11n, IEEE 802.11g, IEEE 802.11g standard
Detect the network and change transmit speed automatically
Support WPA/WPA2/WPA-WPA2/802.1x and 64/128 bit WEP encryption
Support WPS 2.0
Internal Omni-directional Antenna
Support 2.4G and 5G dual band
Support Wi-Fi Direct
Support Multiple BSSID
Support QoS-WMM, WMM-PS
Support WPS: PIN, PBC
Support Infrastructure mode, Ad-Hoc mode and Soft AP three modes
Support Cisco CCX
Low consumption management
Supported OS: Windows XP, 2000, Vista, Windows 7,Win8, Linux
Specification
Wireless Standards IEEE 802.11n
IEEE 802.11g
IEEE 802.11b
IEEE 802.11ac
IEEE 802.11a
Transmit Speed 802.11b: 1/2/5.5/11Mbps
802.11g: 6/9/12/18/24/36/48/54Mbps
802.11n: up to 300Mbps
802.11n: up to 867Mbps
Frequency Range 2.412~2.4835 GHz
5.180~5.320GHz
5.500~5.700GHz
5.745~5.825GHz
Work Channel 1 ~ 14 (2.4G)
36 ~ 165 (5G)
Work Power 18dBm (Typical)
Sensitivity 11n: -68dBm@130M; -68dBm@108M
11g: -69dBm@54M
11b: -85dBm@11M
11ac: -59dBm@867M
Wireless Security WPA/WPA2/WPA-WPA2/802.1x
64/128 bit WEP
WPS (PIN, PBC)
Support Operation System Window 2000/XP/Vista/Win7/Win8Mac OS/Linux
Host Interface USB 2.0
LED(BLUE) Link/Act
Antenna Type External 2dBi Antenna
Size(cm) 9.1×3×1.2
Environment Operating Temperature: 0℃~45℃
Storage Temperature: -20℃~75℃
Operating Humidity: 10% ~ 90% RH (Non Condensing)
Storage Humidity: 5% ~ 95% RH (Non Condensing)
