A pair of Cable Assembly N Bulkhead Female to SMA Male

Electrical Specifications
Model N B/H F-SMA M
Frequency RangE DC to 6GHz
Connector N Bulkhead Female to SMA Male
Cable length 150mm
Impedance 50ohms
Temperature -40℃ to +85℃
Rated Voltage AC 60V
Contact Resistance 20m ohm max-signal and ground
Withstand Voltage AC 200V
Insulation Resistance 500M ohm minimum/DC 100V
VSWR ＜1.5:1
