Manufacturer: MikroTik
Code: RB951G-2HnD-NEW
In stock: 0 |
In comparison with previous model RB751G-2HnD, it has more powerful 600Mhz CPU (instead of 400Mhz), more RAM - 128MB instead of 64MB, all in the same form factor. The device is very small and will look good in any home or office, wall mounting anchor holes are provided.
Product code | RB951G-2HnD |
CPU nominal frequency | 600 MHz |
CPU core count | 1 |
Size of RAM | 128 MB |
10/100/1000 Ethernet ports | 5 |
Wireless chip model | AR9344 |
Wireless standards | 802.11b/g/n |
Number of USB ports | 1 |
Power Jack | 1 |
PoE in | Yes |
Supported input voltage | 9 V - 30 V |
Dimensions | 113x138x29mm |
Operating System | RouterOS |
Tested ambient temperature | -20C..+50C |
License level | 4 |
Antenna gain DBI | 2.5 |
CPU | AR9344 |
Max Power consumption | Up to 7W |
USB slot type | USB type A |
Number of chains | 2 |
Storage type | NAND |
Storage size | 128 MB |
2.4 GHz | |||
---|---|---|---|
Transmit power (dBm) | Receive Sensitivity | Transmit power (mW) | |
6MBit/s | 30 | -96 | 1000 |
54MBit/s | 25 | -80 | 316 |
MCS0 | 30 | -96 | 1000 |
MCS7 | 23 | -78 | 200 |
Wireless parameters may be limited in software depending on your local regulatory domain
RB951G-2HnD | AR9344 1G all port test | ||||||
Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
Bridging | none (fast path) | 81.0 | 983.7 | 232.0 | 950.3 | 269.6 | 138.0 |
Bridging | 25 bridge filter rules | 81.0 | 983.7 | 86.0 | 352.3 | 87.6 | 44.9 |
Routing | none (fast path) | 81.0 | 983.7 | 210.0 | 860.2 | 226.9 | 116.2 |
Routing | 25 simple queues | 81.0 | 983.7 | 103.9 | 425.6 | 106.6 | 54.6 |
Routing | 25 ip filter rules | 56.8 | 689.8 | 59.6 | 244.1 | 60.5 | 31.0 |
