Manufacturer: Teltonika
Code: 003R-00253
In stock: 0 |
Artikel | Spezifikationen | |
GPS&GLONASS-Antenne | Frequenz | 1575.42~1610MHz |
Impendance | 50Ω | |
Polarisation | RHCP | |
Dimension | 25*25*6mm | |
Gewinnen | 28±2dB | |
V. S. W. R | <2.0 | |
Rauschzahl | <1,5 dB | |
Versorgungsspannung | 3~5V DC | |
Stromaufnahme | < 15mA | |
LTE Antenne MIMO | Frequenzbereich | 698~960MHz/1710~2690MHz |
V. S. W. R | <3.0 | |
Polarisation | Lineare | |
Gewinnen | 3 dBi | |
Impendance | 50Ω | |
WIFI-Antenne MIMO
| Frequenzbereich | 2400~2483,5 MHz/4900~5825MHz |
V. S. W. R | <2.5 | |
Polarisation | Lineare | |
Gewinnen | 2dBi | |
Impendance | 50Ω | |
Mechanische | Kabel | RG174 |
Kabel-Länge | 3m | |
Anschluss | SMA oder andere | |
Radom Material | ABS | |
Montage-Methode | Schraube | |
Umwelt | Betriebstemperatur | -40℃~+85℃ |
Relative Luftfeuchtigkeit | Bis zu 95% | |
Schutzart | IP67 (ohne Kabelausgang) | |
Vibration | 10 bis 55Hz, 1,5 mm amplitude 2 Stunden | |
Umweltfreundlich | ROHS-Konform |
